SAUC Minimal Systems
SAUC
Experience the perfect blend of modern luxury and high-performance engineering. At Al Fanous, we bring you SAUC Minimal Systems, a premium range of aluminium solutions designed to maximize your vision and connect your indoor spaces with the world outside.
The SAUC Product Portfolio
We offer five distinct product lines, each engineered for specific architectural requirements:
SAUC 32 – Minimal Slider
The versatile slim-frame solution for standard luxury residential projects.
SAUC 34 – Minimal Slider
Our flagship system, balancing ultra-thin sightlines with the capacity for massive glass panes (up to 4500mm high).
SAUC 44 – Minimal Slider
The heavy-duty variant designed for extreme spans, supporting up to 18 sq. meters of glass per leaf.
SAUC 34 Facade
A specialized “Transparent Architecture” system with a uniquely slim 35mm face-width, offering a high-performance alternative to traditional curtain walls.
SAUC 34 Casement
Slimline hinged windows (top-hung or parallel-opening) that integrate seamlessly into facade systems for ventilation.
Technical Excellence & Performance
Following data iThe s compiled from the SAUC Technical Specification Sheets and Official Product Brochures (SAUC 32/34/44/Facade series):
| Feature | Performance Specification | Source Reference |
|---|---|---|
| Max Sash Height | Up to 4500 mm | SAUC 34 Brochure |
| Max Glass Area | Up to 18 sq. meters per leaf | SAUC 44 Brochure |
| Glass Thickness | 32mm to 34mm (supports lamination) | SAUC General Profile |
| Sound Insulation | Up to 40 db | SAUC 44 Tech Sheet |
| Security Rating | Up to RC-4 (Burglary Resistance) | SAUC 44 Tech Sheet |
| Thermal Efficiency | Uw values up to 0.79 W/m²K (Facade SI) | SAUC 34 Facade Brochure |
| Sightline (Facade) | Ultra-slim 35 mm | SAUC 34 Facade Brochure |
Customization & Design Possibilities
Tailor your architectural elements to match your unique design sensibilities with options sourced from our “Possibilities” Design Guide:
- Typologies: Choose from 2-track, 3-track, or up to 6-track systems.
- Specialized Designs: Including Vertical Slides (Guillotine), Curved Sliding, Pivot Doors, and Corner Post-Free openings.
- Invisible Integration: Latent Inside/Outside technology hides all mechanisms within the floor and ceiling for a completely seamless look.
- Anti-bacterial Powder Coating for healthcare or high-hygiene environments.
- Motorization: Fully automated movement integrated with Home Automation systems.
- Accessibility: Level thresholds specifically designed for Wheelchair Access.
- Safety: Options for Bullet-Proof glass and integrated glass balustrades (railings).
Safety & Security Systems
Security is integrated into the core engineering. As detailed in the SAUC Hardware Catalog, we offer five primary locking variants:
- Electro Drop Bolt Lock (For smart-entry integration)
- Up-Down Lock
- Key Cylinder Lock
- Self-Locking Mechanisms
- 180° Locking Systems
Expert Partnership
With over 40 years of experience in aluminium engineering, Al Fanous provides 360-degree support, from R&D and design to professional installation and after-sales service. Our systems are tested by international agencies to ensure they surpass the test of time in harsh climatic conditions.
